Product type: LM Pro8
Pixel pitch: 8.9mm
Brightness: 3000nits-4000nits
Cabinet material: Die Cast Aluminum
The birth of LM-PRO just for achieving our customer’s every stage deductive value.
It’s not only pursuing the perfect appearance, but also for a better stage display effect: to make sure each circuit is well-arranged, each screw is solid and reliable;
every process is tempered;our pursuit is to let each of your activities is vivid, beautiful and perfect…
Parameters | Value |
Product type | LM-Pro8 |
Pixel pitch(mm) | 8.9 |
Pixel configuration | SMD 3 IN 1 |
Pixel Density(Pixels/㎡) | 12,544 |
Module size(mm) | 500×125 |
Cabinet size(W*H*D mm) | 500×1000×60 |
Brightness(cd/㎡) | 4000 ≥ & ≥3000 |
Viewing Angle(H/V) | H:140/V:100 |
Display Refrest Rate(Hz) | ≥ 1920/3840 |
Cabinet Material | Die Cast Aluminum |
Cabinet weight(kg) | ≈11.5kg |
Input Power Frequency(Hz) | 50/60 |
Input voltage(Nominal)(V) | 220V(110/110-220) |
Input Power(Max)(W/㎡) | 400 |
Input Power(Average)(W/㎡) | 200 |
Lifespan(H) | ≥50,000 |
1.Different from the traditional aluminum cabinet, the die-casting aluminum cabinet stitching has higher accuracy, it’s disassembly
and maintenance is extremely convenient.
2.Point-by-point calibration and high-end display technology is with a high refresh rate, high gray level, high contrast and vivid
showing effect.
3.Patented design without fan achieve no noise, low power consumption, and can be used in temperature range of -30-60 degrees.
4.The design of straight edge or beveled edges can be use to create a curved screen.
5. Permeability is better and cabinet is thinner.
6.The size of 500X1000 is the ideal choice use in stage background, bar, wedding ceremony and other applications.
