H5

Product type: H5


Pixel pitch: 5.2mm 5.95mm


Brightness: ≥1000nits


Cabinet material: Powder Coated Steel


Excellent Design


1. High Density,High Definition Full Color Screen


    - It's better for closer view with high density screen.


2. High Refresh Rate,High Scale Level


    - Much more vivid image display performance satisfies the commercial high visual quality requirements.


3. Dot-to-Dot Color and Brightness correction system


    - Dot-to-Dot correction system-on site large screen dot-to-dot correction processes on the picked spot where is suitable for audience,ensuring screen's higher uniformity when viewing from the suitable spot.


4. Support Multi-Media Play


    - Without transforming format, con directly paly video formats, like: RM,RMVB,MPET-1/2, DAT, AVI, DIVX,XVID,VOB,etc.








Parameters Value
Product type
H5 H5
Pixel pitch(mm)
5.2 5.95
Pixel configuration
SMD3528
SMD3528
Module size(mm)
250*250
250*250
Cabinet size(W*H*D mm)
500×1000×100
500×1000×100
Pixel Density(Pixels/㎡)
36864 28224
Brightness(cd/㎡)
≥1000(2500)
≥1000(2500)
Cabinet Material
Poweder Coated Steel
Poweder Coated Steel
Cabinet weight(kg)
≈20kg
≈20kg
Input Power Frequency(Hz)
50/60
50/60
Input voltage(Nominal)(V)
AC110, 220, 110-220
AC110, 220, 110-220









Applications


 Products of H series, mainly used in  stage rental, television, theater, hotel
